FEATURES AND BENEFITS

• The standard is a microprocessor controller for reactivation
  rate and safeguard functions, and also for heating and
  cooling functions if these options are present. Terminal strip
  connection points are included for customer use for
  alarming, monitoring, and for communication with a
  building management system.


• Each unit is ETL Listed and approved. Every item shipped
  carries a full ETL approval including all options in compliance
  with the current mechanical code. We also have the
  ETL-C listing for Canadian projects. On European projects,
  we can provide country-specific C-E approvals.




• The microprocessor reactivation controller maintains a
  constant burner-output temperature, so burning the
  desiccant rotor is unlike other manufactures. In addition,
  modulating via a reset schedule minimizes energy use.
  Full-rated performance is available in cool weather
  because it is not necessary to limit the firing rate as
  other manufacturers do.

Reactivation temperature sensors are 500°F rated Platinum thermistors.		< Our reactivation burner flame safeguard system is an industrial Honeywell R7895A instead of a commercial-or residential style “ignition module.” The standard gas train on gas-fired units is an ANSI type, and includes inlet regulator, automatic main and pilot valves, an electronic modulating valve, in addition to safety manual valves.
The units use combination circuit breaker/overload/ starters for fan motors. This eliminates the need for spare power fuses, and saves the customer downtime because, if an upset occurs, a simple reset will bring the unit back online.>
		Electric heater banks with individual circuit breaker protection. < Wiring to industrial terminal strips makes for easier connection and troubleshooting.
A remote humidistat with cord. >
Graphic Function Display annunciation panel to provide indication of operation status. >
		< A full-perimeter sprocket with a #40 molly chain drives our desiccant rotor. This is more durable than any other system on the market.
		< Stabilized silica gel is permanently bonded to a low specific-heat substrate for long-lasting dehumidification performance at maximum efficiency. The desiccant rotor rim and cassette are Stainless Steel for durability and strength. < Our desiccant rotor seals are dual-contact, Viton extruded seals, designed to last for the life of the unit. This is the most durable seal in the industry.
Standard Blowers are backward inclined, nonoverloading rated for total static pressure. Wherever possible, blowers are directly coupled to fans to eliminate belts and external bearings. >
